. 10K ohm. 20mm body diameter. 3mm shaft diameter. 10,000,000 turns life.)
Specifications
| Attribute | Value |
| Series / Type | MT20HS / Hybrid Multi-Turn Potentiometer |
| Mounting / Bearing | Servo Mount / Ball Bearings |
| Number of Turns | 10 Turns (3600º) |
| Resistance Value | 10K ohms ±5% |
| Linearity | 0.25% |
| Resolution | Infinite |
| Operating Temperature | -55ºC to +105ºC |
| Power | 2.0W |
| Life Expectancy | 10,000,000 Turns |
| Body Diameter | 20 mm |
| Shaft Diameter | 3 mm |
| Shaft Length | 16.5 mm |
| IP Rating | IP40 |
