Precision Linear Motion Potentiometers

Precision Linear Motion Potentiometers

Linear displacement sensors for distance measurement

The most cost-effective method for measuring mechanical linear motion is the proven linear potentiometer. Measuring lengths of 8mm up to 1500mm. Wide variety of mounting styles and mechanical interfaces; push rod shafts with or without spring loading, rod end bearings, sliding cursor (shaftless), threaded shaft ends, probe tips, through shaft (rear shaft). High resolution (essentially infinite) and high measuring dynamics (shock, vibration, speed, etc.) to meet the requirements for industrial use. Absolute position sensing, signals and measured values ​​are retained (true power on) even if the supply voltage is interrupted.

Our linear motion potentiometers have applications across all industrial sectors; process control automation, heavy equipment, hydraulic machinery, manufacturing automation, valve controllers, medical equipment, aerospace, material handling equipment, etc.

Customization

Should your application require special adaptations to one of our existing products or a completely new design, we can partner with you to deliver a sensor to your specifications. It is not unusual for fractional measuring lengths, improved precision, temperature tolerance or special wiring requirements to be met for serial or occasional production.

Browse by Measurement Distance (Stroke Length), Shaft Type & more Hide Filters Show Filters
Measurement Distance (Stroke Length)
Shaft Type
Shaft Spring Return
Protection Class

Show More

  • LMC8-8 R10K ±15% L1% Series - Linear Motion Potentiometer With Infinite Resolution | Large Image
    Choose Options

    LMC8 Series

    8mm up to 13mm stroke lengths. Precision linear motion potentiometer. 8mm x 7mm low profile housing. 20 million cycle life.
    $35.00 - $50.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Miniature. Through shaft. Precision. Measuring Distance (Stroke Length) 8, 11, 12 and 15 mm Spring...
    $35.00 - $50.00
    Choose Options
  • LMC13-12 R5K ±20% L2% Threaded Shaft Linear Motion Potentiometer | Small Image
    Choose Options

    LMC13 Series

    12mm up to 100mm stroke lengths. Precision linear motion potentiometer. Threaded shaft end. 12mm x 11mm low profile housing. 20 million cycle life.
    $66.00 - $110.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Miniature. Precision. Measuring Distance (Stroke Length) 12, 25, 50 and 100 mm Spring Return No Element Conductive...
    $66.00 - $110.00
    Choose Options
  • Cable version
    Connector version
    Choose Options

    SLPC Series

    10mm up to 300mm stroke lengths. Precision linear motion potentiometer. Dual rod end (heim) bearings. Ø18mm aluminum housing. 75 million cycle life. IP65.
    $129.00 - $208.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Rod end bearings. Industrial. IP65. Measuring Distance (Stroke Lengths) 10 mm up to 300 mm  Spring...
    $129.00 - $208.00
    Choose Options
  • CFL Series
    CFL Series
    Choose Options

    CFL Series

    50mm up to 610mm stroke lengths. Precision linear motion potentiometer. Open frame, sliding cursor (shaftless). Low profile aluminum housing. 20 million cycle life.
    $96.00 - $465.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Sliding cursor Measuring Distance (Stroke Length) 50, 100, 200, 300, 400 and 610 mm (customs welcome) Mechanical End Stops Only...
    $96.00 - $465.00
    Choose Options
  • LMT Series / Linear Motion Potentiometer
    Choose Options

    LMT Series

    14mm up to 25mm stroke lengths. Precision linear motion potentiometer. 16mm x 13mm low profile aluminum housing. Threaded shaft end. 50 million cycle life. IP63.
    $81.00 - $86.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Miniature. Metal Housing. Precision. IP63. Measuring Distance (Stroke Length) 10, 14 and 25 mm Spring...
    $81.00 - $86.00
    Choose Options
  • MBX Series / Open Frame Linear Motion Potentiometer
    Choose Options

    MBX Series

    50mm up to 200mm stroke lengths. Precision linear motion potentiometer. Open frame, sliding cursor (shaftless). Low profile aluminum housing. 5 million cycle life.
    $134.00 - $162.00
    Short Description About 9 weeks delivery if not in stock. --- Specifications Attribute Value Type Open frame. Precision. Long life. Measuring Distance (Stroke Length) 100, 150 and 200 mm Mechanical End...
    $134.00 - $162.00
    Choose Options
  • OPH Series Open Frame Linear Potentiometer
    OPH Linear Potentiometer
    Choose Options

    OPH Series

    50mm up to 1000mm stroke lengths. Precision linear motion potentiometer. Open frame, sliding cursor (shaft-less). Low profile aluminum housing. 75 million cycle life.
    $85.00 - $263.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Sliding cursor Measuring Distance (Stroke Length) 50, 100, 150, 200, 250, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850,...
    $85.00 - $263.00
    Choose Options
  • LMCR8 Series / Linear Motion Potentiometer w/Shaft Spring Return (Through Shaft)
    External spring
    Choose Options

    LMCR8 Series

    8mm up to 15mm stroke lengths. Precision linear motion potentiometer. Shaft spring return (internal). 8mm x 7mm low profile housing. 20 million cycle life.
    $50.00 - $82.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Shaft spring. Miniature. Through shaft. Measuring Distance (Stroke Length) 8, 11, 12 and 15 mm Spring Return Yes: ...
    $50.00 - $82.00
    Choose Options
  • LMCR13 Series / Linear Motion Potentiometer w/Shaft Spring Return
    Choose Options

    LMCR13 Series

    12mm up to 100mm stroke lengths. Precision linear motion potentiometer. Shaft spring return (external). Threaded shaft end. 12mm x 11mm low profile housing. 20 million cycle life.
    $91.00 - $135.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Shaft spring. Miniature. Precision. Measuring Distance (Stroke Length) 12, 25, 50 and 100 mm Spring Return Yes...
    $91.00 - $135.00
    Choose Options
  • LMC15-10 R5K ±10% L2% Threaded Shaft End Linear Motion Potentiometer | Large Image
    Choose Options

    LMC15 Series

    10mm up to 30mm stroke lengths. Precision linear motion potentiometer. Threaded shaft end. 24mm x 15mm low profile housing. 20 million cycle life.
    $49.00 - $91.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Miniature. Through shaft. Measuring Distance (Stroke Length) 10, 15, 20 and 30 mm Spring Return No Element Conductive...
    $49.00 - $91.00
    Choose Options
  • LMCR15 Series / Linear Motion Potentiometer w/Shaft Spring Return
    Choose Options

    LMCR15 Series

    10mm up to 30mm stroke lengths. Precision linear motion potentiometer. Shaft spring return (internal). Threaded shaft end. 24mm x 15mm low profile housing. 20 million cycle life.
    $74.00 - $108.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Series / Type Shaft spring. Miniature. Precision. Measuring Distance (Stroke Length) 10, 15, 20 and 30 mm Spring Return Yes...
    $74.00 - $108.00
    Choose Options
  • RTL Series - Linear Motion Potentiometer
    Choose Options

    RTL Series

    30mm up to 1000mm stroke lengths. Precision linear motion potentiometer. Threaded shaft end. 33mm x 33mm profile aluminum housing. 75 million cycle life. IP65.
    $104.00 - $268.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Industrial. IP65. Measuring Distance (Stroke Lengths) 30 mm up to 1000 mm Spring Return No Element Conductive...
    $104.00 - $268.00
    Choose Options
  • LPC Series - Precision Linear Motion Potentiometer
    Choose Options

    LPC Series

    50mm up to 750mm stroke lengths. Precision linear motion potentiometer. Dual rod end (heim) bearings. Ø35mm aluminum housing. 75 million cycle life. IP65.
    $155.00 - $292.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Rod end bearings. Heavy duty. IP65. Measuring Distance (Stroke Lengths) 50 up to 800 mm Spring...
    $155.00 - $292.00
    Choose Options
  • Cable version
    Connector version
    Choose Options

    SLPS Series

    10mm up to 100mm stroke lengths. Precision linear motion potentiometer. Shaft spring return (external). Probe tip shaft end. Ø18mm aluminum housing. 75 million cycle life. IP65.
    $149.00 - $219.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type External Shaft spring. Industrial. IP65. Measuring Distance (Stroke Lengths) 10 mm up to 100 mm Spring Return Yes (external...
    $149.00 - $219.00
    Choose Options
  • SLPIS Series / Linear Motion Potentiometer cable output
    SLPIS Series / Linear Motion Potentiometer connector output
    Choose Options

    SLPIS Series

    10mm up to 100mm stroke lengths. Precision linear motion potentiometer. Shaft spring return (internal). Probe tip shaft end. Ø18mm aluminum housing. 75 million cycle life. IP65.
    $116.00 - $202.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Internal Shaft spring. Industrial. IP65. Measuring Distance (Stroke Length) 10 mm up to 100 mm Spring Return Yes (internal...
    $116.00 - $202.00
    Choose Options
  • SLPK Linear Transducer Cable Type
    SLPK Linear Transducer onnectorType
    Choose Options

    SLPK Series

    10mm up to 200mm stroke lengths. Precision linear motion potentiometer. Through shaft with M5 threaded shaft ends (both ends). Ø18mm aluminum housing. 100 million cycle life. IP65.
    $122.00 - $208.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type SLPK slim line series Measuring Distance (Stroke Lengths) 10 mm up to 200 mm Spring Return No  Element Conductive...
    $122.00 - $208.00
    Choose Options
  • SLPKS Series / Linear Motion Potentiometer
    SLPKS Series / Linear Motion Potentiometer
    Choose Options

    SLPKS Series

    10mm up to 100mm stroke lengths. Precision linear motion potentiometer. Shaft spring return (external). Probe tip shaft end. Ø18mm aluminum housing. 75 million cycle life. IP65.
    $167.00 - $229.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type External Shaft spring. Industrial. IP65. Measuring Distance (Stroke Lengths) 10 mm up to 100 mm Spring Return Yes (external...
    $167.00 - $229.00
    Choose Options
  • Cable version
    Connector version
    Choose Options

    SLPT Series

    10mm up to 400mm stroke lengths. Precision linear motion potentiometer. Threaded shaft end. Ø18mm aluminum housing. 75 million cycle life. IP65.
    $114.00 - $196.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Industrial. Precision. IP65. Measuring Distance (Stroke Lengths) 10 mm up to 400 mm Spring Return No Element Conductive...
    $114.00 - $196.00
    Choose Options
  • LPH Series / Linear Motion Potentiometer
    Choose Options

    RPH Series

    100mm up to 1750mm stroke lengths. Precision linear motion potentiometer. Sliding cursor (shaftless) with threaded pivot linkage. 38mm x 38mm profile. 75 million cycle life
    $160.00 - $410.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Sliding cursor. Metal housing. Precision. Measuring Distance (Stroke Lengths) 100 up to 1750 mm Spring...
    $160.00 - $410.00
    Choose Options
  • ELPC Series - Linear Motion Potentiometer with integrated signal conditioner.
    Choose Options

    ELPC Series

    50mm up to 750mm stroke lengths. Precision linear motion potentiometer with internal signal conditioner. 0-10V, 4-20mA or 0-20mA output (24V supply). Dual rod end (heim) bearings. Ø35mm aluminum housing. 75 million cycle life. IP65.
    $179.00 - $247.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Rod end bearings, IP65, Internal signal conditioner. Measuring Distance (Stroke Length) 50 up to 750 mm Spring...
    $179.00 - $247.00
    Choose Options
  • ERPH Series
    Choose Options

    ERPH Series

    100mm up to 1750mm stroke lengths. Precision linear motion potentiometer with internal signal conditioner. 0-10V, 4-20mA or 0-20mA output (24V supply). Sliding cursor. Threaded pivot linkage. 38mm x 38mm profile. 75 million cycle life. IP65.
    $184.00 - $343.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Sliding Cursor. Built in signal conditioner. Measuring Distance (Stroke Length) 100 up to 1750 mm Spring Return No Output...
    $184.00 - $343.00
    Choose Options
  • ERTL Series - Linear Motion Potentiometer w/ integrated signal conditioner.
    Choose Options

    ERTL Series

    30mm up to 1000mm stroke lengths. Precision linear motion potentiometer with internal signal conditioner. 0-10V, 4-20mA or 0-20mA output (24V supply). Threaded shaft end. 33mm x 33mm profile aluminum housing. 75 million cycle life. IP65.
    $141.00 - $175.00
    Short Description About 5 weeks delivery if not in stock. --- Specifications Attribute Value Type Internal Signal Conditioner. IP65. Measuring Distance (Stroke Length) 30 mm up to 1000 mm Spring Return No Output...
    $141.00 - $175.00
    Choose Options
  • RC13 Series / Linear Motion Potentiometer

    RC13M Series

    25mm up to 250mm stroke lengths. Precision linear motion potentiometer. Threaded shaft end. Ø13mm low profile aluminum housing. 100 million cycle life. IP60.
    $219.00 - $255.00
    Short Description --- Specifications Attribute Value Type 13mm diameter. Precision. Long life. Measuring Distance (Stroke Lengths) 25 mm up to 250 mm Spring Return No Element Conductive plastic Resistance Value /...
    $219.00 - $255.00
  • REM13 Series / Linear Motion Potentiometer
    Choose Options

    REM13 Series

    50mm up to 1000mm stroke lengths. Precision linear motion potentiometer. Magnetic coupled sliding cursor. Ø13mm aluminum housing . 100 million cycle life. IP67.
    $270.00 - $495.00
    Short Description --- Specifications Attribute Value Type IP67. Fully sealed. Sliding cursor. Measuring Distance (Stroke Lengths) 50 mm up to 1000 mm Cursor Sliding. Magnetically coupled Element Conductive...
    $270.00 - $495.00
    Choose Options
  • HEM12 100 I K R5K W20% L0.05% / Linear Motion Potentiometer

    HEM12 Series

    50mm up to 1000mm stroke lengths. Precision linear motion potentiometer. Magnetic coupled sliding cursor. 250 bar / 400 bar (peak) for in cylinder applications. Ø13mm stainless steel housing. 100 million cycle life. IP67.
    $345.00
    Short Description About 10 weeks delivery if not in stock. --- Specifications Attribute Value Type Magnetic cursor. IP67+. Stainless steel. 250 bar. Measuring Distance (Stroke Length) 50mm up to 1000 mm Cursor Sliding...
    $345.00
  • HEM16 150 E K3 R5K W20% L0.05% / Linear Motion Potentiometer
    Choose Options

    HEM16 Series

    50mm up to 1000mm stroke lengths. Precision linear motion potentiometer. Magnetic coupled sliding cursor. 250 bar / 400 bar (peak) for in cylinder applications. Ø16mm stainless steel housing. 100 million cycle life. IP67.
    $509.00
    Short Description About 10 weeks delivery if not in stock. --- Specifications Attribute Value Type Magnetic cursor. IP67+. Stainless steel. 250 bar. Measuring Distance (Stroke Length) 50mm up to 1000 mm Cursor Sliding...
    $509.00
    Choose Options
  • RC20G Series / Linear Motion Potentiometer
    Choose Options

    RC20G Series

    25mm up to 300mm stroke lengths. Precision linear motion potentiometer. Dual rod end (heim) bearings. Ø20mm aluminum housing. 100 million cycle life. IP60.
    $320.00 - $355.00
    Short Description --- Specifications Attribute Value Type Rod end bearings. Metal housing. Long life. Measuring Distance (Stroke Lengths) 25mm up to 300 mm Spring Return No Element Conductive plastic Resistance...
    $320.00 - $355.00
    Choose Options
  • RC35 Series / Linear Motion Potentiometer
    RC35 Series / Linear Motion Potentiometer
    Choose Options

    RC35 Series

    50mm up to 750mm stroke lengths. Precision linear motion potentiometer. Dual rod end (heim) bearings. Ø35mm aluminum housing. 100 million cycle life. IP65.
    $388.00 - $499.00
    Short Description --- Specifications Attribute Value Type Rod end bearings. Heavy duty. Long life. IP65. Measuring Distance (Stroke Lengths) 50 mm up to 750 mm Spring Return No Element Conductive plastic Resistance...
    $388.00 - $499.00
    Choose Options
  • MSL38 Series / Linear Motion Potentiometer
    Choose Options

    MSL38 Series

    100mm up to 2000mm stroke lengths. Precision linear motion potentiometer. Sliding cursor (shaftless) with threaded pivot linkage. 38mm x 38mm profile. 100 million cycle life
    $241.00 - $326.00
    Short Description --- Specifications Attribute Value Type Sliding cursor. Metal housing. Long life. Measuring Distance (Stroke Length) 100 up to 2000 mm Cursor Sliding.(shaftless) Element Conductive...
    $241.00 - $326.00
    Choose Options
  • LMC30 Series
    Choose Options

    LMC30 Series

    200 and 300mm stroke lengths. 5k ohms. M5 threaded shaft end. 0.5% linearity.
    $130.00 - $150.00
    Short Description --- Specifications Attribute Value Series / Type Metal housing. Precision. Measuring Distance (Stroke Length) 200 and 300 mm Spring Return No Element Conductive plastic Resistance Value 5k Ohms...
    $130.00 - $150.00
    Choose Options
  • LMH15 Series / Hall Effect Linear Motion Potentiometer
    Add to Cart

    LMH15-30

    Hall Effect. 30mm stroke length. 5V supply. 0.5 - 4.5V output. 0.5% linearity. IP65
    $112.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Hall effect. 30mm stroke length. 0 - 5V output. IP65. Measuring Distance (Stroke Length) 30 mm Spring Return No Supply...
    $112.00
    Add to Cart
  • LMHR15 Series / Hall Effect Linear Motion Potentiometer w/Shaft Spring Return
    Add to Cart

    LMHR15-30

    Hall Effect. 30mm stroke length. Shaft spring return (external). 5V supply. 0.5 - 4.5V output. 0.5% linearity. IP65
    $121.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Hall effect. Spring loaded. 30mm stroke length. 0 - 5V output. IP65. Measuring Distance (Stroke Length) 30 mm Spring Return Yes...
    $121.00
    Add to Cart

Partner with P3 America for Expert Solutions

Choosing the right motion control technology can be a challenge. Determining what type of linear potentiometer is appropriate for your application can be overwhelming because it takes an expert to understand the variables. P3 America has decades of experience providing applications engineering, rapid prototyping, OEM support, and distribution support. Our industry experts are always available to provide more information on the applications for linear motion pots and custom solutions. We are well versed in the challenges that come in a wide range of industries, so they are equipped to help you find answers. Volume-based discounts are available, even for units purchased over time.

Contact us to speak with an applications engineer about your project. We’ll be able to recommend stock or custom linear motion potentiometers and transducers. If we can’t find the right solution for you, we’ll create it custom.
