SLPT Series

Industrial precision linear motion potentiometer (displacement transducer). Threaded shaft end with swivel joint included. High resolution conductive plastic element. 75 million stroke life. 18mm diameter aluminum housing. IP65. Available in measuring lengths (stroke lengths) of 10mm (max) up to 400mm (max).
SKU:
Select an option below
  • Cable version
  • Connector version
$105.00 - $181.00

About 5 weeks delivery if not in stock.

Pdf Download PDF

Specifications

Attribute Value
Type Industrial. Precision. IP65.
Measuring Distance (Stroke Lengths) 10 mm up to 400 mm
Spring Return No
Element Conductive plastic
Resistance Value (±20%) 2K ohms (<75mm), 5K ohms (75mm to 400mm)
Linearity ±0.5% (<75mm), ±0.2% (75-130mm), ±0.1% (130mm-200mm), ±0.05% (>200mm)
Resolution Infinite
Max Supply Voltage 28 VDC
Operating Temperature -20ºC to +80ºC
Life Expectancy >75,000,000 Reciprocating motions
Body Dimensions Ø18 x (length varies with stroke length, see pdf datasheet)
Shaft Diameter 5 mm
Threaded Shaft End Yes - M5 (swivel joint included with delivery)
Mounting Adjustable clamps (included)
Output Cable Length 1 meter
IP Rating IP65

Main Features

* Threaded shaft end and pivot linkage

* 18mm housing diameter

* Precision linearity

* 75 million cycle life

* IP65  environmental rating

Customization

* Non standard (fractional) measuring stroke lengths

* Improved linearity and/or resistance tolerances

* Customer specified pre-wiring / connectorization

Applications

Optimized to be used as a feedback sensor (closed loop) in industrial applications.

* Robotics

* Factory automation systems

* Process control automation

* Test stands

* Automotive equipment

* Aerospace
