Linear Motion Transducers

Linear Motion Transducers

Linear potentiometers, LVDT inductive displacement transducers, and draw-wire sensors

Types of Linear Transducers

Linear displacement sensors optimized for industrial use. Characterized by robust construction, high precision, and extremely long life. Measuring distances from 2mm up to 42 meters. Wide selection of mounting styles, mechanical connection, and electrical interface. Ingress protection up to IP69K. High shock/vibration tolerance and high dynamics (measuring speed) to meet the rigors of industrial applications.

Our linear motion sensors and position transducers have applications across all industrial sectors; process control automation, heavy equipment, hydraulic machinery, manufacturing automation, valve controllers, medical equipment, aerospace, material handling equipment, etc.

linear transducer

Find the Components You Need

P3 America has stocked—or can engineer—a wide range of linear transducers to meet almost any operational requirement.

Need a special part? Our customization team can build exactly what you need for the best prices in the industry, even for low quantities. With over 40 years of application and production experience, we have the expertise and the skills to help you find the linear transducer or other solutions to your most challenging applications.

Call and talk tech with our engineers right over the phone.
Call (858) 277-1420
Or Email:
sales@p3america.com

Browse by Measurement Distance (Stroke Length), Shaft Type & more Hide Filters Show Filters

Show More

  • LMC8 Series
8mm, 11mm and 12mm stroke lengths
    LMC8 Series
8mm, 11mm and 12mm stroke lengths

    LMC8 Series

    Miniaturized linear potentiometer in 8mm up to 15mm stroke lengths. Front and rear guided shaft. 8mm x 7mm low profile housing. 20 million cycle life.
    $35.00 - $50.00
    Short Description  Manufactured by SAKAE --- Specifications Attribute Value Type Miniature. Through shaft. Precision. Measuring Distance (Stroke Length) 8, 11, 12 and 15 mm Spring Return No Element Conductive...
    $35.00 - $50.00
  • LMCR8 Series w/Internal Spring Return
8mm, 11mm, 12mm stroke lengths
    LMCR8 Series w/Internal Spring Return
15mm stroke length

    LMCR8 Series (w/Shaft Spring)

    Miniaturized linear potentiometer in 8mm up to 15mm stroke lengths. Internal shaft spring return. Front and rear guided shaft. 8mm x 7mm low profile housing. 20 million cycle life.
    $50.00 - $82.00
    Short Description Manufactured by SAKAE --- Specifications Attribute Value Type Shaft spring. Miniature. Through shaft. Measuring Distance (Stroke Length) 8, 11, 12 and 15 mm Spring Return Yes:  internal (<15mm...
    $50.00 - $82.00
  • LMT Series
    LMT Series

    LMT Series

    Miniature displacement sensor. Rugged aluminum housing. 10, 14 and 25 mm stroke lengths. Front and rear guided shaft (through shaft). Compact. Long life and high accuracy. IP54.
    $105.00 - $112.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Conductive plastic linear motion potentiometer Measuring Distance (Stroke Length) 10, 14 and 25 mm Spring Return No Resistance...
    $105.00 - $112.00
  • LMTIS Series
    LMTIS Series

    LMTIS Series

    Miniature displacement sensor with internal shaft spring. Rugged aluminum housing. 10, 14 and 25 mm stroke lengths. Front and rear guided shaft (through shaft). Compact. Long life and high accuracy. IP54.
    $124.00 - $131.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Conductive plastic linear motion potentiometer with internal shaft spring Measuring Distance (Stroke Length) 10, 14 and 25 mm Spring...
    $124.00 - $131.00
  • LMC13-12 R5K ±20% L2% Threaded Shaft Linear Motion Potentiometer | Small Image

    LMC13 Series

    12mm up to 100mm stroke lengths. Precision linear motion potentiometer. Threaded shaft end. 12mm x 11mm low profile housing. 20 million cycle life.
    $66.00 - $110.00
    Short Description Manufactured by SAKAE --- Specifications Attribute Value Type Miniature. Precision. Measuring Distance (Stroke Length) 12, 25, 50 and 100 mm Spring Return No Element Conductive plastic Resistance...
    $66.00 - $110.00
  • LMCR13 Series / Linear Motion Potentiometer w/Shaft Spring Return

    LMCR13 Series

    12mm up to 100mm stroke lengths. Precision linear motion potentiometer. Shaft spring return (external). Threaded shaft end. 12mm x 11mm low profile housing. 20 million cycle life.
    $91.00 - $135.00
    Short Description Manufactured by SAKAE --- Specifications Attribute Value Type Shaft spring. Miniature. Precision. Measuring Distance (Stroke Length) 12, 25, 50 and 100 mm Spring Return Yes...
    $91.00 - $135.00
  • LMC15-10 R5K ±10% L2% Threaded Shaft End Linear Motion Potentiometer | Large Image

    LMC15 Series

    10mm up to 30mm stroke lengths. Precision linear motion potentiometer. Threaded shaft end. 24mm x 15mm low profile housing. 20 million cycle life.
    $49.00 - $91.00
    Short Description  Manufactured by SAKAE --- Specifications Attribute Value Type Miniature. Through shaft. Measuring Distance (Stroke Length) 10, 15, 20 and 30 mm Spring Return No Element Conductive...
    $49.00 - $91.00
  • LMCR15 Series / Linear Motion Potentiometer w/Shaft Spring Return

    LMCR15 Series

    10mm up to 30mm stroke lengths. Precision linear motion potentiometer. Shaft spring return (internal). Threaded shaft end. 24mm x 15mm low profile housing. 20 million cycle life.
    $74.00 - $108.00
    Short Description  Manufactured by SAKAE --- Specifications Attribute Value Series / Type Shaft spring. Miniature. Precision. Measuring Distance (Stroke Length) 10, 15, 20 and 30 mm Spring Return Yes...
    $74.00 - $108.00
  • LMH15 Series / Hall Effect Linear Motion Potentiometer

    LMH15-30

    Hall Effect. 30mm stroke length. 5V supply. 0.5 - 4.5V output. 0.5% linearity. IP65
    $112.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Hall effect. 30mm stroke length. 0 - 5V output. IP65. Measuring Distance (Stroke Length) 30 mm Spring Return No Supply...
    $112.00
  • LMHR15 Series / Hall Effect Linear Motion Potentiometer w/Shaft Spring Return

    LMHR15-30

    Hall Effect. 30mm stroke length. Shaft spring return (external). 5V supply. 0.5 - 4.5V output. 0.5% linearity. IP65
    $121.00
    Short Description About 8 weeks delivery if not in stock. --- Specifications Attribute Value Type Hall effect. Spring loaded. 30mm stroke length. 0 - 5V output. IP65. Measuring Distance (Stroke Length) 30 mm Spring Return Yes...
    $121.00
  • MBX Series / Open Frame Linear Motion Potentiometer

    MBX Series

    50mm up to 200mm stroke lengths. Precision linear motion potentiometer. Open frame, sliding cursor (shaftless). Low profile aluminum housing. 5 million cycle life.
    $134.00 - $162.00
    Short Description 64 weeks delivery. --- Specifications Attribute Value Type Open frame. Precision. Long life. Measuring Distance (Stroke Length) 100, 150 and 200 mm Mechanical End Stops No Element Conductive...
    $134.00 - $162.00
  • CFL Series
    CFL Series

    CFL Series

    50mm up to 610mm stroke lengths. Precision linear motion potentiometer. Open frame, sliding cursor (shaftless). Low profile aluminum housing. 20 million cycle life.
    $96.00 - $465.00
    Short Description Manufactured by SAKAE --- Specifications Attribute Value Type Sliding cursor Measuring Distance (Stroke Length) 50, 100, 200, 300, 400 and 610 mm (customs welcome) Mechanical End Stops Only on 'ES'...
    $96.00 - $465.00
  • OPH Series
Open Frame Linear Potentiometer
    OPH Linear Potentiometer

    OPH Series

    Open frame linear potentiometer. Sliding cursor (shaftless). 50mm up to 1000mm stroke lengths. Low profile aluminum housing. High precision and long life.
    $94.00 - $308.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Open frame (sliding cursor) conductive plastic linear potentiometer Measuring Distance (Stroke Lengths) 50, 100, 150, 200, 250, 300, 350, 400, 450,...
    $94.00 - $308.00
  • Cable version
    Connector version

    SLPC Series

    Compact with dual rod end bearings. 10mm up to 400mm stroke lengths. Precision linearity and very long life. Ø18mm aluminum housing. IP65.
    $134.00 - $243.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Compact  linear displacement transducer with rod end bearings Measuring Distance (Stroke Lengths) 10 mm up to 400 mm Repeatability < 0.01...
    $134.00 - $243.00
  • SLPIS Series / Linear Motion Potentiometer
cable output
    SLPIS Series / Linear Motion Potentiometer
connector output

    SLPIS Series (w/Shaft Spring)

    Internal shaft spring. 10mm up to 100mm stroke lengths. Probe tip shaft end. Ø18mm aluminum housing. Long life and high accuracy. IP65.
    $134.00 - $194.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Precision potentiometer with internal shaft spring. Measuring Distance (Stroke Length) 10 mm up to 100 mm Spring Return Yes (internal...
    $134.00 - $194.00
  • SLPS Linear Motion Potentiometer
Cable Version
    SLPS Linear Motion Potentiometer
Connector Version

    SLPS Series (w/Shaft Spring)

    External shaft spring. 10mm up to 100mm stroke lengths. Probe tip shaft end. Ø18mm aluminum housing. Long life and high accuracy. IP65.
    $163.00 - $253.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type External Shaft spring. Industrial. IP65. Measuring Distance (Stroke Length) 10 mm up to 100 mm Spring Return Yes (external...
    $163.00 - $253.00
  • SLPK Linear Potentiometer
Cable connection
    SLPK Linear Potentiometer
Connector

    SLPK Series

    Through shaft with M5 threaded shaft ends. 10 mm up to 200 mm stroke lengths. Ø18mm aluminum housing. Long life and high accuracy. IP65.
    $140.00 - $233.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Precision conductive plastic linear potentiometer Measuring Distance (Stroke Lengths) 10 mm up to 200 mm Spring...
    $140.00 - $233.00
  • SLPKS Series / Linear Motion Potentiometer
Cable connection
    SLPKS Series / Linear Motion Potentiometer
Connector

    SLPKS Series (w/Shaft Spring)

    External shaft spring. 10mm up to 100mm stroke lengths. Probe tip shaft end. Ø18mm aluminum housing. Long life and high accuracy. IP65.
    $131.00 - $219.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type External Shaft spring. Industrial. IP65. Measuring Distance (Stroke Length) 10 mm up to 100 mm Spring Return Yes (external...
    $131.00 - $219.00
  • Cable version
    Connector version

    SLPT Series

    Swivel joint for lateral misalignment. 10mm up to 400mm stroke lengths. Precision linearity and long life. Ø18mm aluminum housing. IP65.
    $122.00 - $243.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Potentiometric Linear Displacement Sensor Measuring Distance (Stroke Lengths) 10 mm up to 400 mm Spring Return No  Element Conductive...
    $122.00 - $243.00
  • LSC Series

    LSC Series

    Ø25 mm aluminum housing. M14 threaded bushing . M5 threaded shaft end. 25mm up to 400mm stroke lengths. High accuracy and 100 million movements life. IP65.
    $241.00 - $325.00
    Short Description 3 - 5 weeks delivery if not in stock. Manufactured by OPKON --- Specifications Attribute Value Type Metal Housing with Bushing Mount. Heavy duty. IP65. Measuring Distance (Stroke Lengths) 25 up to 400...
    $241.00 - $325.00
  • ELSC Series

    ELSC Series

    Inernal signal conditioner; 0-10V or 4-20mA otutput. Ø25 mm aluminum housing. M14 threaded bushing . M5 threaded shaft end. 25mm up to 400mm stroke lengths. High accuracy and 100 million movements life. IP65.
    $340.00 - $433.00
    Short Description 3 - 5 weeks delivery. Manufactured by OPKON   --- Specifications Attribute Value Measuring Distance (Stroke Lengths) 50, 75, 100, 125, 150, 200, 250, 300, 350, 400 (mm) Linearity ±0.5% (≤75mm),...
    $340.00 - $433.00
  • LPC Series  - Precision Linear Motion Potentiometer
    Shaft side rod end bearing

    LPC Series

    Heavy duty linear potentiometer with dual rod end (heim) bearings. Ø35mm aluminum housing. 50mm up to 800mm stroke lengths. High precision and excellent repeatability. 100 million movements life. IP65.
    $181.00 - $329.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Heavy duty linear displacement transducer with rod end bearings Measuring Distance (Stroke Lengths) 50 up to 800 mm Resistance Value 5k ohms (50...
    $181.00 - $329.00
  • ELPC Series - Linear Motion Potentiometer with integrated signal conditioner.
    shaft side rod end bearing

    ELPC

    Internal signal conditioner; 0-10V or 4-20mA output. Measuring lengths of 50mm up to 750mm. Dual rod end (heim) bearings. Ø35mm aluminum housing. 100 million movements life. IP65.
    $222.00 - $329.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Measuring Distance (Stroke Lengths) 50, 75, 100, 125, 150, 200, 250, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800 (mm) Linearity ±0.5%...
    $222.00 - $329.00
  • RTL Series - Linear Motion Potentiometer

    RTL Series

    33mm x 33mm aluminum housing. Up to 1000mm stroke lengths. Threaded shaft end or swivel bearing. High accuracy, long life and excellent repeatability. IP65.
    $120.00 - $308.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Type Industrial linear potentiometer. Measuring Distance (Stroke Lengths) 30 up to 1000 mm Resistance Value 5k ohms (50 - 600 mm), 10k ohms (650...
    $120.00 - $308.00
  • ERTL Series - Linear Motion Potentiometer w/ integrated signal conditioner.

    ERTL Series

    Internal signal conditioner; 0-10V or 4-20mA output. 30mm up to 1000mm stroke lengths. Threaded shaft end. 33mm x 33mm profile aluminum housing. 100 million movements life. IP65.
    $161.00 - $214.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Measuring Distance (Stroke Lengths) 30, 50, 75, 100, 125, 150, 200, 250, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 950, 1000...
    $161.00 - $214.00
  • LPH Series / Linear Motion Potentiometer
    Sliding cursor with pivot linkage

    RPH Series

    Sliding cursor with pivot linkage. 33" x 33" profile. Measuring lengths of 100mm up to 1950mm. High accuracy and long life. IP40.
    $185.00 - $555.00
    Short Description 3 - 5 weeks delivery. Manufactured by OPKON --- Specifications Attribute Value Type Sliding cursor with pivot linkage for lateral misalignment Measuring Distance (Stroke Lengths) 100 up to 1950 mm Resistance...
    $185.00 - $555.00
  • ERPH Linear Displacement Sensor
    Sliding cursor with pivot linkage

    ERPH Series

    Internal signal conditioner; 0-10V or 4-20mA output. Sliding cursor with pivot linkage. 33" x 33" profile. Measuring lengths of 100mm up to 1950mm. High accuracy. 100 million movements life. IP40
    $230.00 - $478.00
    Short Description Manufactured by OPKON --- Specifications Attribute Value Measuring Distance (Stroke Lengths) 100, 125, 150, 200, 250, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 950, 1000.......1950...
    $230.00 - $478.00
  • REM13 Series / Linear Motion Potentiometer

    REM13 Series

    50mm up to 1000mm stroke lengths. Precision linear motion potentiometer. Magnetic coupled sliding cursor. Ø13mm aluminum housing . 100 million cycle life. IP67.
    $310.00 - $495.00
    Short Description --- Specifications Attribute Value Type IP67. Fully sealed. Sliding cursor. Measuring Distance (Stroke Lengths) 50 mm up to 1000 mm Cursor Sliding. Magnetically coupled Element Conductive...
    $310.00 - $495.00
  • HEM12 100 I K R5K W20% L0.05% / Linear Motion Potentiometer

    HEM12 Series

    50mm up to 1000mm stroke lengths. Precision linear motion potentiometer. Magnetic coupled sliding cursor. 250 bar / 400 bar (peak) for in cylinder applications. Ø13mm stainless steel housing. 100 million cycle life. IP67.
    $345.00
    Short Description About 10 weeks delivery if not in stock. --- Specifications Attribute Value Type Magnetic cursor. IP67+. Stainless steel. 250 bar. Measuring Distance (Stroke Length) 50mm up to 1000 mm Cursor Sliding...
    $345.00
  • HEM16 150 E K3 R5K W20% L0.05% / Linear Motion Potentiometer

    HEM16 Series

    50mm up to 1000mm stroke lengths. Precision linear motion potentiometer. Magnetic coupled sliding cursor. 250 bar / 400 bar (peak) for in cylinder applications. Ø16mm stainless steel housing. 100 million cycle life. IP67.
    $509.00
    Short Description About 10 weeks delivery if not in stock. --- Specifications Attribute Value Type Magnetic cursor. IP67+. Stainless steel. 250 bar. Measuring Distance (Stroke Length) 50mm up to 1000 mm Cursor Sliding...
    $509.00
  • MH60 - Draw Wire Sensor
    MH60 - Draw Wire Sensor

    MH60 Series

    Draw wire sensor for construction machinery and mobile hydraulic applications. 1...4 meters measuring lengths. Analog output signals (potentiometer, 0...5V, 0....10V or 4 - 20mA). ±0.5% linearity (0.25% or 0.1% option). IP67 (IP69K option)
    $302.00 - $528.00
    Short Description 6 - 8 weeks delivery. --- Specifications Attribute Value Type Draw Wire Sensor Measurement Range 1, 1.5, 2, 2.5, 3, 3.5 and 4 meters Analog Output potentiometer (1 kΩ), 0...5 V, 0...10 V, 0...5 V...
    $302.00 - $528.00
  • MH120 - Draw Wire Sensor
    MH120 - Draw Wire Sensor

    MH120 Series

    Draw wire sensor optimized for offshore and port applications. 3...10 meters measuring lengths. Analog output signals (potentiometer, 0...5V, 0....10V or 4 - 20mA). ±0.5% linearity (0.25% or 0.1% option). IP67 (IP69K option)
    $402.00 - $638.00
    Short Description 6 - 8 weeks delivery. --- Specifications Attribute Value Type Draw Wire Sensor Measurement Range 3, 4, 5, 6, 7, 8, 9 or 10 meters Output Signals potentiometer (1 kΩ), 0...5 V, 0...10 V, 0...5 V...
    $402.00 - $638.00
  • Draw Wire Mechanics for Encoder Assembly
    SX135 Mechanics
Up to 42.5 meters measuring length

    SX Mechanics Series

    Draw wire sensor mechanics for encoder attachment. From 1 meter up to 42.5 meters measuring. Encoder requirements: clamping flange (36 mm), shaft diameter (10 mm), shaft length (20 mm). Simple installation.
    Short Description 6 - 8 weeks delivery. --- Specifications Attribute Value Type SX135 Mechanics Series for Encoder Assembly Measurement Range from 1 meter up to 42.5 meters Encoder Requirements clamping flange diameter: 36...
  • SXM30 Series

    SXM30 Series

    New miniature draw wire sensor with housing diameter of 31mm (the size of a bottle cap). Measuring lengths of up to 750mm. Precision potentiometer output (1kΩ, 5kΩ, 10kΩ). Ideal for medical applications.
    $188.00 - $262.00
    Short Description 6 - 8 weeks delivery. --- Specifications   Attribute Value Type Miniature Draw Wire Sensor. Industrial. Precision. Measurement Range (mm) Economy Version: 500 and 700  /  Standard Version: 150,...
    $188.00 - $262.00
  • SX50 - Draw Wire Sensor
    SX50 - Draw Wire Sensor

    SX50 Series

    Draw wire sensor. Cost-effective and flexible solution for a wide range of industrial applications. 50...1250 millimeters measuring lengths. Analog output signals (potentiometer, 0....10V or 4 - 20mA). ±0.5% linearity. IP65 (IP67 option)
    $375.00 - $558.00
    Short Description 6 - 8 weeks delivery. --- Specifications   Attribute Value Type Draw Wire Sensor. Industrial. Precision. Measurement Range 50, 75, 100, 125, 150, 225, 250, 300, 375, 500, 625, 750, 1000 and 1250...
    $375.00 - $558.00
  • SX80 - Draw Wire Sensor
    SX80 - Draw Wire Sensor

    SX80 Series

    Draw wire sensor. Cost-effective and flexible solution for a wide range of industrial applications. 1000...3000 millimeters measuring lengths. Analog output signals (potentiometer, 0....10V or 4 - 20mA). ±0.5% linearity. IP65 (IP67 option)
    $475.00 - $713.00
    Short Description 6 - 8 weeks delivery. --- Specifications Attribute Value Type Draw Wire Sensor. Industrial. Precision. Measurement Range 1000, 1500, 2000, 2500 and 3000 millimeters Analog Output potentiometer (1...
    $475.00 - $713.00
  • SX120 - Draw Wire Sensor
    SX120 - Draw Wire Sensor

    SX120 Series

    Draw wire sensor. Cost-effective and flexible solution for a wide range of industrial applications. 3...5 meters measuring lengths. Analog output signals (potentiometer, 0....10V or 4 - 20mA). ±0.1% linearity. IP65 (IP67 option)
    $604.00 - $815.00
    Short Description 6 - 8 weeks delivery. --- Specifications Attribute Value Type Draw Wire Sensor Measurement Range 3 meters, 4 meters and 5 meters Analog Output potentiometer (1 kΩ),  0...10 V, 0...5 V (teachable),...
    $604.00 - $815.00
  • SX135 - Draw Wire Sensor
    SX135 - Draw Wire Sensor

    SX135-8 Series

    Draw wire sensor. Cost-effective and flexible solution for a wide range of industrial applications. 6, 7 and 8 meter measuring lengths. Analog output signals (potentiometer, 0....10V or 4 - 20mA). ±0.1% linearity. IP65 (IP67 option)
    $782.00 - $982.00
    Short Description 6 - 8 weeks delivery. --- Specif Specifications Attribute Value Type Draw Wire Sensor. Industrial. Precision. Measurement Range 6, 7 and 8 meters Analog Output potentiometer (1 kΩ),  0...10 V, 0....
    $782.00 - $982.00
  • SX135 - Draw Wire Sensor
    SX135 - Draw Wire Sensor

    SX135-40 Series

    Draw wire sensor with snap back protection options. 10...42.5 meters measuring lengths. Analog output signals (potentiometer, 0....10V or 4 - 20mA). ±0.1% linearity. IP65 (IP67 option)
    $1,181.00 - $1,724.00
    Short Description 6 - 8 weeks delivery. --- Specifications Attribute Value Type Draw Wire Sensor. Industrial. Precision. Measurement Range 10, 12, 15, 20, 25, 30, 35, 40 and 42.5 meters Analog Output potentiometer (1...
    $1,181.00 - $1,724.00
  • ISDL Series

    ISDL Series

    Unguided armature LVDT w/built in signal processor. 2, 5, 10, 20, 50, 100 and 200mm stroke lengths. Output signal: 0 - 5V, 0-10V, ±5V, ±10V, 4-20mA or 0-20mA. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $422.00 - $742.00
    Short Description About 4 weeks delivery if not in stock. --- Specifications Attribute Value Type Unguided Armature LVDT w/internal signal conditioning. IP65+. Measuring Distance (Stroke Length) 2, 5, 10, 20, 50, 100 and...
    $422.00 - $742.00
  • ISDT series - spring loaded LVDT with probe tip

    ISDT Series

    LVDT w/built in signal processor. 2, 5, 10, 20 and 50mm stroke lengths. Output signal: 0 - 5V, ±5V, 0-10V, ±10V, 0-20mA or 4-20mA. 0.75% linearity. Shaft spring (external). 1 meter cable length. IP65.
    $541.00 - $618.00
    Short Description About 4 weeks delivery if not in stock. --- Specifications Attribute Value Type Spring loaded LVDT w/internal signal conditioner. IP65. Measuring Distance (Stroke Length) 2mm, 5mm, 10mm, 20mm and 50mm...
    $541.00 - $618.00
  • IEDT 10 K 2410 Internal Signal Processor

    IEDT Series

    LVDT w/built in signal processor. 2, 10, 20 and 50mm stroke lengths. Output signal: 0-10V, 4-20mA or 0-20mA. 0.75% linearity. Shaft spring (external). 1 meter cable length. IP65.
    $345.00 - $392.00
    Short Description About 4 weeks delivery if not in stock. --- Specifications Attribute Value Type Spring loaded LVDT w/internal signal conditioner. IP65. Measuring Distance (Stroke Length) 2mm, 10mm, 20mm and 50mm...
    $345.00 - $392.00
  • IGAT Series LVDT w/M12 Connector

    IGAT Series

    Spring loaded shaft LVDT (AC output). M18 threaded housing. 2, 5, 10 and 20mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+
    $318.00 - $367.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type LVDT (AC) w/Shaft spring return. IP65+. Measuring Distance (Stroke Length) 2, 5, 10 and 20 mm Sensitivity (mV/V/mm) Varies with stoke length (see...
    $318.00 - $367.00
  • IGDT Series

    IGDT Series

    M18 threaded body LVDT w/built in signal processor. 2, 5, 10 and 20mm stroke lengths. Output signal: 0 - 5V, 0-10V, ±5V, 4-20mA or 0-20mA. Linearity: 0.5% (0.25% option). Shaft spring (internal). 1 meter cable length. IP65+.
    $384.00 - $437.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Spring loaded LVDT, Built in signal conditioner. IP65+. Measuring Distance (Stroke Length) 2, 5, 10 and 20 mm Spring Return Yes...
    $384.00 - $437.00
  • IGAL Series
Linear Variable Transducer

    IGAL Series

    Unguided armature LVDT (AC output). M18 threaded housing. 2, 5, 10 and 20mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+
    $294.00 - $333.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type LVDT (AC) w/unguided armature. IP65+. Measuring Distance (Stroke Length) 2, 5, 10 and 20 mm Sensitivity (mV/V/mm) Varies with stoke length (see...
    $294.00 - $333.00
  • IGDL Series

    IGDL Series

    Unguided armature LVDT. M18 threaded body. Built in signal processor. 2, 5, 10, 20mm stroke lengths. Output signal: 0 - 5V, 0-10V, ±5V, 4-20mA or 0-20mA. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $349.00 - $403.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Unguided armature LVDT w/internal signal conditioner. Measuring Distance (Stroke Length) 2, 5, 10, 20mm Spring Return No Supply Voltage 24...
    $349.00 - $403.00
  • IMAT Series
    IMAT Series

    IMAT Series

    Spring function LVDT (AC output). M12 threaded body. 2, 5, 10 and 20mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $274.00 - $320.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Spring function LVDT (AC output). M12 threaded body. IP65. Measuring Distance (Stroke Length) 2, 5, 10 and 20 mm Sensitivity (mV/V/mm) Varies...
    $274.00 - $320.00
  • IMDT Series LVDT w/M12 connector
    IMDT Series LVDT w/cable output

    IMDT Series

    M12 threaded body LVDT w/built in signal processor. 2, 5, 10 and 20mm stroke lengths. Output signal: 0 - 5V, 0-10V, ±5V. Linearity: 0.5% (0.25% option). Shaft spring (internal). 1 meter cable length. IP65+.
    $337.00 - $380.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type LVDT (DC) Measuring Distance (Stroke Length) 2, 5, 10 and 20 mm Spring Return Yes (internal) Supply Voltage 24 VDC ±20% Output...
    $337.00 - $380.00
  • IMAL Series
    Unguided armature

    IMAL Series

    Unguided armature LVDT (AC output). M12 threaded body. 2, 5, 10 and 20mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $246.00 - $290.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Unguided armature LVDT (AC). IP65. Measuring Distance (Stroke Length) 2, 5, 10 and 20 mm Sensitivity (mV/V/mm) Varies with stoke length (see pdf...
    $246.00 - $290.00
  • IMDL Series LVDT
    IMDL Series

    IMDL Series

    Unguided armature LVDT. M12 threaded body. Built in signal processor. 2, 5, 10, 20mm stroke lengths. Output signal: 0 - 5V, 0-10V, or ±5V. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $290.00 - $333.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Unguided armature LVDT. M12 threaded body. Built in signal processor. IP65. Measuring Distance (Stroke Length) 2, 5, 10, 20mm Spring...
    $290.00 - $333.00
  • ISAG Series

    ISAG Series

    Rod end bearing LVDT (AC output). 2, 5, 10, 20, 50, 100 and 200mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $368.00 - $519.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Rod End Bearing LVDT (AC output). IP65+ Measuring Distance (Stroke Length) 2, 5, 10, 20, 50 mm  (100 and 200mm on request) Sensitivity...
    $368.00 - $519.00
  • ISDG Series

    ISDG Series

    LVDT w/built in signal processor. 5, 10, 20, 50, 100 and 200mm stroke lengths. Output signal: 0 - 5V, 0-10V, ±5V, ±10V, 4-20mA or 0-20mA. Linearity: 0.5% (0.25% option). Rod end bearings. 1 meter cable length. IP65+.
    $511.00 - $780.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Rod End Bearing LVDT w/built in signal conversion. IP65. Measuring Distance (Stroke Length) 5, 10, 20, 50, 100 and 200mm Spring...
    $511.00 - $780.00
  • IZAL Series

    IZAL Series

    Miniature unguided armature LVDT (AC output). 4mm diameter. 2, 5 and 10mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65.
    $598.00 - $667.00
    Short Description 4 - 6 weeks delivery, --- Specifications Attribute Value Type 4mm diameter. Unguided armature LVDT (AC Output). IP65. Measuring Distance (Stroke Length) 2, 5 and 10 mm Sensitivity (mV/V/mm) Varies with stoke...
    $598.00 - $667.00
  • IKAT Series
    IKAT Series

    IKAT Series

    Spring function LVDT (AC output). 2, 5, 10 & 20mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+
    $297.00 - $347.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type 8mm diameter LVDT (AC). Spring loaded. IP65. Measuring Distance (Stroke Length) 2, 5, 10 and 20 mm Sensitivity (mV/V/mm) Varies with stoke length...
    $297.00 - $347.00
  • IKAL Series

    IKAL Series

    Unguided armature LVDT (AC output). 2, 5, 10 and 20mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65.
    $270.00 - $339.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type 8mm diameter LVDT (AC). Unguided armature. IP65. Measuring Distance (Stroke Length) 2, 5, 10 and 20 mm Sensitivity (mV/V/mm) Varies with stoke...
    $270.00 - $339.00
  • ISAT Series

    ISAT Series

    Spring function LVDT (AC output). 2, 5, 10, 20 & 50mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $368.00 - $488.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Spring loaded LVDT (AC Output). IP65+. Measuring Distance (Stroke Length) 2, 5, 10, 20, 50, 100 and 200mm Sensitivity (mV/V/mm) Varies with stoke...
    $368.00 - $488.00
  • ISAL Series

    ISAL Series

    Unguided armature LVDT (AC output). 2, 5, 10, 20, 50, 100 and 200mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $230.00 - $480.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Series / Type Unguided armature LVDT (AC output). IP65+. Measuring Distance (Stroke Length) 2, 5, 10, 20, 50, 100 and 200mm Sensitivity...
    $230.00 - $480.00
  • ISAL-KD Series

    ISAL-KD Series

    Unguided armature LVDT (AC output). 2, 5, 10, 20, 50, 100 and 200mm stroke lengths. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $256.00 - $302.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Unguided armature LVDT (AC Output). IP65+. Measuring Distance (Stroke Length) 2, 5, 10, 20, 50, 100 and 200mm Sensitivity (mV/V/mm) Varies with...
    $256.00 - $302.00
  • ISDL-KD Series

    ISDL-KD Series

    Through shaft unguided armature LVDT w/built in signal processor. 2, 5, 10, 20, 50, 100 and 200mm stroke lengths. Output signal: 0 - 5V, 0-10V, ±5V, ±10V, 4-20mA or 0-20mA. Linearity: 0.5% (0.25% option). 1 meter cable length. IP65+.
    $368.00 - $647.00
    Short Description 4 - 6 weeks delivery. --- Specifications Attribute Value Type Unguided armature LVDT w/DC output. IP65+. Measuring Distance (Stroke Length) 2, 5, 10, 20, 50, 100 and 200mm Spring Return No Supply...
    $368.00 - $647.00

Types of Linear Motion Transducers

Linear displacement transducers (linear sensors) are available in five different measurement principles:

  • Linear potentiometer
  • Inductive (LVDT)
  • Magnetostrictive
  • Draw Wire Sensors (Cable Transducer, String pots)
linear-motion-transducer-diagram

Linear Motion Potentiometers

Linear potentiometers are passive components utilizing conductive plastic or wire-wound resistive elements in specific lengths (2mm up to 2000mm). The wiper (slider) is moved over the resistance element providing a linear change in output voltage relative to the measuring length. Linear potentiometers are types of linear transducers with three connections: two for the resistor ends and one for the wiper (slider).

  • Simple sensor principle, mostly without electronics
  • Measured value is instantaneous and absolute
  • Resolution is essentially infinite
  • Economical and available in a wide variety of styles
  • Works with low voltages (minimal power consumption)
  • Insensitive to magnetic interference fields

We have a wide range of linear motion potentiometers with a standard IP65 rating and some IP67 options.

Outputs of Linear Motion Potentiometers

Linear potentiometers provide an analog voltage output varying from 0 volts up to the applied voltage. Assuming 10V is applied, the output would be 0 - 10V over the stroke length. With 5V applied, the output is 0 - 5V.

Some of the models have a built-in signal conditioner that can provide either a 0 - 10V output or a 4 - 20mA output. In this case, the required supply voltage must be 15V - 30V.

lvdt-circuit-diagram

Linear Variable Displacement Transducers (LVDT)

The LVDT is an absolute analog position sensor that is based on inductive technology consisting of a primary coil and two secondary coils. These coils convert the motion of the shaft as a linear transducer into electrical signals that can be processed for accurate control and measurement. Being inductive, the sliding wiper used with potentiometers is not required, and thus, is wear-free.

  • Sealed sensor (high IP protection)
  • High precision linearity
  • Able to measure micro displacements
  • Near infinite resolution
  • Durable, consistent accuracy
  • Maintenance and wear-free
  • Suitable for high dynamics
  • Reproducible zero point
  • Absolute signal output
  • Insensitive to many chemicals

Our LVDT range of products are rated at IP65 with IP67 options.

Outputs of Linear Variable Displacement Transducer (LVDT)

The LVDT native output is in mV/V requiring external signal conditioning to provide an analog voltage or milli-amp output.

Some of the models have a built-in signal conditioner capable of either voltage or milli-amp outputs.

lvdt-transducer-output-diagram

Magnetostrictive Linear Sensors

Magnetostrictive linear sensors, also known as analog magnetostrictive linear transducers, are robust, absolute measuring systems with a resolution of up to 2 µm. The measured values are made without contact, so the sensor has an unlimited life and is wear and maintenance-free. The sensor consists of a robust housing, a waveguide inside, an external sliding magnet (donut cursor) that deflects the generated pulses, and a converter that converts the returning vibrations into an electrical signal. The position of the magnet is then determined by magnetostriction.

  • Sealed sensor (high IP protection) with electronics
  • Contactless measuring principle
  • Maintenance- and wear-free
  • Durable, consistent accuracy
  • Long measuring distances up to 4000 mm
  • Insensitive to shock and vibration
  • Withstands high pressures - ideal for hydraulically moved axes
  • Insensitive to many chemical media

The Magnetostrictive range of position sensors are rated at IP65 with IP67 options.

Outputs of Magnetostrictive Linear Sensors

Analog magnetostrictive linear transducers are available with 0-10V, 10-0V, 0-20 mA, 20-0 mA, 4-20 mA, and 20-4 mA outputs. The supply voltage is 24VDC.

Digital magnetostrictive position sensors are provided with a Profinet or Profibus interface.

magnetostrictive-linear-sensor-parts-diagram

Draw Wire Sensors

These linear transducers are commonly referred to as cable transducers or string potentiometers (string pots). The key component of a draw wire sensor is a highly flexible steel wire rope that is wound single-layered on an ultra-light capstan. This capstan is connected to the sensor housing by a pre-stressed spring. The end of the steel wire rope is equipped with a clip that gets connected to the target object. As soon as the distance between the sensor and the target object changes, the steel wire rope gets pulled out of the sensor and is rolled off the capstan (or vice versa). The shaft of the capstan is connected to a precision potentiometer (for analog output signals), or to an encoder (for digital output signals). If there is a rotation of the capstan due to a change in the distance to the target object, the sensor element will turn proportionally. This way the potentiometer, or the encoder converts a linear movement into a proportional electrical signal.

  • Measurement ranges from 50 mm up to 50000 mm
  • High dynamics: travel speed up to 10 m/s
  • Durable, consistent accuracy
  • Specialized for mobile hydraulic applications
  • Protection class up to IP69k
  • Easy mounting
  • Operating Temperature -20...+85 °C (optional -40 °C or +120 °C)
  • Can be mounted remotely from the target to be measured

The majority of draw wire sensor models are rated at IP65 with IP67 and IP69K options.

Outputs of Draw Wire Sensors

Analog output options include 0...5 V, 0...10 V, and 4...20 mA.

Digital output options include TTL, HTL, SSI, Profibus, CANopen, EtherCAT, and Profinet.

Contact P3 America

P3 America has been a leading provider of economical sensors, linear motion transducers, and positioning products. Our extensive product selection allows us to address your needs promptly and effectively. With some of the best delivery times in the industry, we can help your operation to continue running smoothly and help your bottom line grow.

For more information on our products and services, contact us today.

Call Now: (858) 277-1420

Or Email:

sales@p3america.com
