LMCR13 Series

Precision linear potentiometer (displacement transducer) with spring loaded shaft (external spring). Threaded shaft end. Essentially infinite resolution conductive plastic element. 13mm x 11mm housing. 20 million stroke life. Measuring lengths (stroke lengths) of 12 / 25 / 50 / 100 mm.
SKU:
Select an option below
$91.00 - $135.00

About 8 weeks delivery if not in stock.

Specifications

Attribute Value
Type Shaft spring. Miniature. Precision.
Measuring Distance (Stroke Length) 12, 25, 50 and 100 mm
Spring Return Yes (external)
Element Conductive plastic
Resistance Value Various. See Configurations above and pdf datasheet
Linearity Varies with stroke length. See Configurations above and pdf datasheet
Resolution Infinite
Power See pdf
Operating Temperature -30ºC to +105ºC
Life Expectancy >20,000,000 Reciprocating motions
Body Dimensions (width x height) 13w x 11h mm (length varies with stroke, see pdf)
Shaft Diameter 1/8" (3.17mm)
Threaded Shaft End Yes (M3 thread)
Electrical Connection Turret terminals
Mounting Through holes in body
IP Rating IP40

Main Features

* Shaft spring (external)

* Low profile 13mm x 11mm housing

* Precision linearity

* Long life

Customization

* Without a shaft spring (see LMC13 series)

* Non standard (fractional) measuring stroke lengths

* Improved linearity and/or resistance tolerances

* Customer specified pre-wiring / connectorization

* Shaft modifications

Applications

Optimized to be used as a feedback sensor (closed loop) in industrial applications.

* Machinery automation

* Moulding machinery

* Measuring equipment

* Medical equipment

* Valve actuators

* Test stands
