CFL Series

Precision linear motion potentiometer (displacement transducer). Open frame with sliding cursor (wiper). Essentially infinite resolution. Long life (20 million cycles). Available in measuring lengths of 50mm (max) up to 610mm (max).
SKU:
Select an option below
  • CFL Series
  • CFL Series
$110.00 - $465.00

About 8 weeks delivery if not in stock.

Specifications

Attribute Value
Type Sliding cursor
Measuring Distance (Stroke Length) 50, 100, 200, 300, 400 and 610 mm (customs welcome)
Mechanical End Stops Only on 'ES' types
Element Conductive Plastic
Resistance Value varies, see individual models above
Linearity ±0.5% (1% for 50mm stroke)
Resolution Infinite
Power varies with stroke length, see pdf
Operating Temperature -30ºC to +105ºC
Life Expectancy >20,000,000 Reciprocating Motions
Dimensions varies with stroke length, see pdf
Mounting Screw Hole
IP Rating IP40



Main Features

* Low profile

* 50mm up to 610mm stroke lengths

* Aluminum housing

* High precision

* Long life

Customization

* Non standard (fractional) measuring stroke lengths

* Improved linearity and/or resistance tolerances

* Customer specified pre-wiring / connectorization

* With or without mechanical end stops

Applications

Optimized to be used as a feedback sensor (closed loop) in industrial applications.

* Medical devices

* Robotics

* Test Stands

* Aerospace
