MH120 Series

Draw wire sensor MH120 - Ideal for offshore and port applications. Oil platforms, port facilities and offshore wind farms present a variety of challenges to sensitive equipment such as sensors. Temporary submersion and aggressive seawater stress the material and reduce the life span. The IAP option for draw wire sensors of the MH120 series is ideal for mastering these conditions. The sensors achieve optimum protection with a housing and a sealed spring package made of corrosion-resistant aluminium, which is additionally coated with Hartcoat®. Due to the high protection class of IP69K, the draw wire sensors can also be cleaned by using steam and high-pressure equipment. Measuring lengths of up to 10 m with a linearity of up to ±0.1 % allow a wide variety of applications. The use of a wire rope made of Coramid or V4A stainless steel and the optional saltwater-resistant pulley UR4 allow measurements to be taken below the water surface. The draw wire sensors are available with potentiometer output, the common analog outputs 4...20 mA, 0...5 V and 0...10 V as well as the digital output CANopen. These outputs are also available in redundant versions.
SKU:
Select an option below
  • MH120 - Draw Wire Sensor
  • MH120 - Draw Wire Sensor
  • MH120 - Draw Wire Sensor
$344.00 - $623.00

3 - 5 weeks delivery.

Specifications

Attribute Value
Type Draw Wire Sensor
Measurement Range 3, 4, 5, 6, 7, 8, 9 or 10 meters
Output Signals potentiometer (1 kΩ), 0...5 V, 0...10 V, 0...5 V (teachable), 0...10 V (teachable), 4...20 mA
Linearity ±0.5% (optional: ±0.25% or ±0.1%)
Resolution Infinite
Power Supply 12....30 VDC
Mechanical Data extraction force, maximum velocity and acceleration - see 'Mechanical Data' in pdf datasheet
Connection M12 radial connector (optional; cable output axial (TPE cable, standard length 2m)
Protection Class IP67, (optional IP69K, only in combination with cable output)
Humidity maximum 90% relative, no condensation
Working Temperature -20ºC...+85ºC (optional: -40º...+85ºC)
Temperature Coefficient varies with Output Signal type (see datasheet)
Housing Aluminum, anodized, spring case PA6
