MT46S-10 R10K ±3% L0.1% A19.05 DM6.35

46mm diameter. 3, 5, 10, 15 and 20 turns. Wire-wound. Bushing mount. 1/4" shaft diameter. Precision linearity. Long life.

10 turns. 10k ohms. Hybrid element. Servo mount. 6mm shaft diameter. 0.25% linearity. 5 million turns life.

285º measuring angle (continuous, without end stop). Heavy duty all metal housing. Oil filled for harsh environments. Precision wire wound potentiometer. 10k ohms. 0.5% linearity. 5mm shaft diameter. M8 x 0.75 threaded bushing (sleeve bearing). IP6

Heavy duty - oil filled (harsh environs). IP65. 285º measuring angle (continuous, without end stop). Metal housing. Precision conductive plastic potentiometer. 10k ohms. 1% linearity. 5mm shaft diameter. M8 x 0.75 threaded bushing (sleeve bearing).

285º measuring angle (with mechanical end stop). Heavy duty all metal housing. Oil filled for harsh environments. Precision wire wound potentiometer. 5K ohms. 2% linearity. 5mm shaft diameter. M8 x 0.75 threaded bushing (sleeve bearing). IP65.

355º measuring angle (continuous rotation, without end stop). High precision wire-wound potentiometer. 1,000,000 turns life. 51mm housing diameter. 6mm shaft diameter. 18mm shaft length (FMS). Servo mount (ball bearings). IP40.

Hybrid element, long life. 20mm diameter. 10 turns. 10k ohms. Servo mount. 3mm shaft diameter. 0.25% linearity.

Single axis. ±15º travel. Spring return center. 10K ohm potentiometer. IP54.

46mm diameter. 20 turns. Limit switches. 1k ohms. 10 watts. Wire-wound. Bushing mount. 6mm shaft diameter. 0.3% linearity.
