R25W R10K L1%

SKU:
R25W-C100-R10K

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

Buy 5 - 9 and pay only $5.70 each
Buy 10 - 19 and pay only $5.42 each
$6.00

Please contact us

Specifications

Attribute Value
Series / Type R25W / Single Turn Wire-Wound Potentiometer
Electrical Angle 270º
Mechanical Angle 285º (mechanical end stops)
Bearing Sleeve
Resistance Value 10k ohms ±10%
Linearity Tolerance ±1.0%
Resolution 0.15%
Operating Temperature -40ºC to +105ºC
Power 1.0 W
Life Expectancy >100,000 Turns
Body Diameter 25 mm
Shaft Diameter 6.35mm (1/4")
Mounting Threaded bushing (3/8-32)
IP Rating IP40
