IEDT Series

LVDT displacement sensor with spring loaded shaft. Integrated signal conditioner provides DC output (0-10V, 0-20mA or 4-20mA). 20mm housing diameter. Connection via 1 meter length output cable. IP65. High resolution, contactless measuring method for extremely long service life. Measured value retention (true power on) even if the supply voltage is interrupted. Measuring lengths (stroke lengths) of 2 / 10 / 20 / 50 mm.

SKU:

Select an option below

Specifications
Main Features
Customization
Applications

Specifications

Attribute	Value
Type	Spring loaded LVDT w/internal signal conditioner. IP65.
Measuring Distance (Stroke Length)	2mm, 10mm, 20mm and 50mm versions
Spring Return	Yes (external)
Supply Voltage	24 VDC ±5%
Output	0-10 V / 4-20mA / 0-20 mA
Linearity	±0.75%
Resolution	Infinite
Current Consumption	50 mA (no load)
Operating Temperature	0ºC to +60ºC
Life Expectancy	>100,000,000 Reciprocating Motions
Body Diameter	20 mm
Shaft Diameter	4 mm
Cable Output	1 meter length
IP Rating	IP65

Main Features

* 20mm diameter ruggedized aluminum housing

* Integrated electronics

* Probe tip

* Shaft Spring (External)

* Extremely Long life

* Suitable for high dynamics

* For harsh environmental conditions (up to IP67)

Customization

* Non standard (fractional) measuring stroke lengths

* 0-10 V / 4-20mA / 0-20 mA output signal options

* Customer specified pre-wiring / connectorization

Applications

* Gauging instruments

* In-process gauging devices

* High-reliability servo systems

* Measurement instruments

* Precision Robotics

* Metering

* Automation

* Hydraulics

* Aircraft system

* Machine Tools

* Labs

* Robotics
