SXM30 Series

Ultra compact precision draw wire sensor. Measurement ranges from 150 to 750 mm. Economy version for ranges 500 and 750 mm. Output potentiometer: 1 kΩ, 5 kΩ or 10 kΩ. Linearity up to ±0.1% of full scale. Protection class up to IP50. Temperature range up to -40...+85 °C. Compact, perfect for medical applications.

SKU:

Select an option below

Condition:

New

Specifications

Specifications

Attribute	Value
Type	Miniature Draw Wire Sensor. Industrial. Precision.
Measurement Range (mm)	Economy Version: 500 and 700 / Standard Version: 150, 225, 250, 375, 500, 700
Analog Potentiometer Output	Economy Version: 1kΩ / Standard Version: 1kΩ, 5kΩ, 10kΩ
Linearity	Economy Version: ±0.25% / Standard Version: ±0.2% (150, 225, 250, 375mm) ±0.1% (500 & 700mm)
Resolution	Economy Version: 0.03% / Standard Version: Infinite (limited only by power supply ripple voltage)
Power Supply	max. 30V
Mechanical Data	extraction force, maximum velocity and acceleration - see 'Mechanical Data' in pdf datasheet
Connection	Solder terminals
Protection Class	IP40: 500, 700mm / IP50: 150, 225, 250, 375mm
Humidity	maximum 90% relative, no condensation
Working Temperature	Economy Version: -20ºC...+80ºC / Standard Version: -40º...+80ºC
Temperature Coefficient	±0.0025 %/K
Housing	Aluminum, anodized, spring case PA6
