ERCF Series

Hall effect precision potentiometer. Flange mount. True 360º measuring angle or any fraction. Analog voltage or milliamp output options. Custom modifications such as fractional measuring angle, shaft modifications and customer specified wiring available. High precision, long life. IP65 protection grade.
SKU:
Select an option below
$46.00 - $60.00
Pdf Data Sheet Cad CAD Files

Specifications

Attribute Value
Series / Type ERC / Hall Effect Potentiometer - Flange Mount
Electrical Angle 360º
Mechanical Angle 360º (continuous)
Supply Voltage 5V up to 30V (see pdf, depends on output)
Output 0 - 5V, 0 - 10V, 4 - 20mA, 0 - 20mA (Optional dual (redundant) output)
Linearity ±0.5%
Resolution 12 Bit
Life Expectancy >10,000,000 Turns
Operating Temperature -40ºC to +85ºC
Mounting Flange
Shaft Diameter 6 mm
Shaft Length 11 mm
IP Rating IP65





Main Features

* Hall effect potentiometer (contactless/wear free)

* Flange mount (sleeve bearing)

* True 360º measuring angle

* 0 - 5V output

* Precision linearity

* 12 bit resolution

* 10,000,000+ turns life

Customization

* Custom measuring angles

* 0-10V, 0-20mA, 4-20mA outputs

* Redundant output

* CCW rising signal

* Customer specified pre-wiring / connectorization

Applications

* Traditional potentiometer replacement

* Set point controller

* Position feed-back sensor

* Valve and Flap control

* Joysticks

* Accelerator Pedals

* Electric wheelchairs

* Servo system

* Steering angle measurement
