HTA25KPM Series

Select an option below
  • HTA25KPM Multi Turn Encoder
Radial connector output
  • HTA25KPM Multi Turn Encoder
Rear connector output
Contact us for details

Multi-Turn Rotary Kit Encoders

Rotary kit encoder in Ø25 mm metal housing with numerous electronic, mechanical and software options

Absolute encoder:*

  • *Maximum shaft rotation in powered-off state without losing reference is ±179º
  • Measuring range up to 72000° (200 shaft revolutions)
  • Programmable are the sense of rotation (CW/CCW) and the effective electrical angle [°]
  • Programmable up to 10,000 times
  • Factory programming: effective electrical angle of rotation 3600° (10 turns), sense rotation CW
  • Supply voltage: 9 to 30 VDC, 15 to 30 VDC
  • Output signal: 4 to 20 mA, 0 to 5 V, 0 to 10 V
  • 12 bit resolution (per turn)

HTA25KPM encoder - robust, ball bearings, sealed

The HTA25KPM multi-turn encoder is a robust encoder with magnetic sensor technology. This is due to the solid aluminum housing, the high IP protection class and a double ball-bearing stainless steel shaft that withstands high axle loads and allows high actuation speeds. The signal processing is digital and based on magnetic recording of measured values. The gradient-based evaluation ensures high interference immunity, e.g. B. against temperature fluctuations and EMC influences achieved. This technology leaves the disadvantages of conventional Hall sensors far behind. HTA25KPM rotary encoders are designed for maximum service life and even surpass the robust optical data acquisition. The number of defects or failures in rotary encoders with this technological design is practically zero, even after decades of use.

Customer specific modifications such as shaft geometries, signal output functions, special cable lengths or individually assembled electrical connection cables are available.


Attribute Value
Series / Type HTA25KPM Series / Multi-Turn Hall Effect Encoders
Resolution 12 bit (per turn)
Output Signal
Analog; 0-5V, 0-10V, 4-20mA
Sensor Technology
Hall Technology
Magnet Proximity to Sensor Face
1 mm (see page 5 of pdf)
Housing Diameter
25 mm
Mounting Flange
Electrical Connection Cable or plug connector
Effective Electrical Angle of Rotation maximum 72000º (200 turns) - Field Programmable
Housing Depth min. 19.35 mm / max. 36.05 mm
