Specifications
| Attribute | Value |
| Series / Type | JC50 - Potentiometer Joystick |
| Number of Axis | Dual |
| Handle Deflection | ±30º (60º overall) |
| Handle Operating Pattern | Type 'X' (see pdf) |
| Resistance Value | 10K ohms (center tapped) |
| Spring Return to Center | Yes |
| Return to Center Accuracy | ±50% ±1.5% |
| Pushbutton on Handle | No |
| Pushbutton Rating | n/a |
| Center Detect Micro-Switch | No |
| Directional Micro-Switches | No |
| Micro-Switch Rating | n/a |
| Operating Temperature | -20ºC to +65ºC |
| Rubber Boot | Yes |
| Mounting Plate | No |
| Life Expectancy | >5,000,000 Random Operations |
| Mounting | Below Panel |
| IP Rating | IP65 (above panel) |
