MT22IR (Slip Clutch) Series

Internal slip clutch for over rotation protection. 22mm (7/8") diameter. 10 turns (3600º). Optimized for position feedback (closed loop) applications in industrial settings. Customization includes different resistance values, shaft modifications and rear shaft extension.
SKU:
MT22IR-3-R10K ±5% L0.25% (211180)
  • P3 America Mt22ir Multi turn Potentiometer Internal Slip Clutch
  • MT22IR / Wire-Wound Multi-Turn Potentiometer w/Internal Slip Clutch
$59.00

Pdf Download PDF Ask A Question

Specifications

Attribute Value
Series / Type MT22IR / Wire-Wound Multi-Turn Potentiometer w/Internal Slip Clutch
Slipping Torque
20mN·m ~ 60mN·m
Mounting / Bearing Bushing Mount / Sleeve Bearing
Number of Turns 1080º (3 Turns) / 1800º (5 Turns) / 3600º (10 Turns)
Resistance Values 100, 200, 500, 1k, 2k, 5k, 10k, 20k, 50k, 100k ohms ±5%
Linearity 0.5% (3 & 5 turns) / 0.25% (10 turns)
Resolution Varies with resistance value (see pdf datasheet)
Operating Temperature -55ºC to +105ºC
Power Rating 1.0W (3 & 5 Turns) / 2.0W (10 Turns)
Life Expectancy 500,000 Turns Life (3 & 5 Turn Models) / 1,000,000 Turns Life  (10 Turn Models)
Body Diameter 22 mm
Shaft Diameter 6.35 mm (1/4")
Shaft Length 20.6 mm
IP Rating IP40

Main Features

* 22mm (7/8") housing diameter

* Internal slip clutch (over rotation protection)

* IGUS rear bearing (improved side load tolerance)

* Precision linearity

* 0.016% resolution

* 1,000,000+ turns life

Customization

* 3 and 5 turn models

* Resistance values up to 50K ohm

* Shaft modifications

* Rear shaft extension

* Customer specified pre-wiring / connectorization

Applications

* Agriculture

* Material equipment

* Process industry

* Electronics & Telecommunications

* Textile

* Electric actuators

* Level measurement

* Process Automation systems

* Signaling and Telecom equipment

* Draw-wire sensor (length sensor)
