P53-80-M18-I-CM12

Stainless steel ultrasonic sensor with teflon mounting nuts.

SKU:
517634
$590.00

3 - 5 weeks delivery

  • Sensing Distance: 120 - 800 mm
  • Output: 4...20mA
  • Connection: CM12
  • Set Point Adjustment: -
  • Housing: M18 - Stainless Steel
  • Mounting: Teflon mounting nuts included
  • Features: Fully encapsulated - IP67

Applications

• Distance measurement of moving machine parts

• Detection of moving objects made of all materials, including glass

• Presence detection of objects and humans

• Counting of objects with various shapes

• Completeness control of objects in bundles (bottles in a box)

• Level measurement of bulk goods storage and liquids in silos and containers

• Winding and unwinding control of rolls in paper-, coils- textile industries

• Web tension control in a multi-level working process

• Sorting control by measuring the height profile of packaging items

• Position control by measuring the stacking height and overlaps on loaders

• Area Monitoring

• Collision avoidance in the case of automated guided vehicles
