STCS50 Series

350º measuring angle. Servo mount (ball bearings). High precision conductive plastic potentiometer. 50,000,000 turns life. 50mm housing diameter. 6mm shaft diameter. Metal housing. IP40. Optimized for feedback sensor in industrial control applications. Customs welcome, please provide details.
SKU:
STCS50 R5K ±5% L0.1% (242124)
Condition:
New
$198.00
Pdf Data Sheet Cad CAD Files

Specifications

Attribute Value
Series / Type STCS50 / Single Turn Conductive Plastic Potentiometer
Electrical Angle 350º
Mechanical Angle 360º (continuous)
Bearing Ball bearings
Resistance Value 500, 1k, 2k, 5k, 10k, 20k, 50k, 100k ohms   ±5%
Linearity Tolerance ±0.1%
Resolution Infinite
Operating Temperature -55ºC to +125ºC
Power 3.0 W
Life Expectancy >50,000,000 Turns
Body Diameter 50 mm
Shaft Diameter 6 mm
Shaft Length 16.5 mm
Mounting Servo collar
IP Rating IP40
