Specifications
Attribute | Value |
Series / Type | SWS4 Series / Switch Joystick |
#Axis | Single or Dual Axis / ±12º Handle Deflection |
Spring Return to Center | Yes |
Micro Switch Rating | 5A / 250 VAC |
Push Button Handle | Yes |
Push Button Handle Rating | 0.1A / 50 VDC |
Push Button Color | Black |
Operating Temperature | -20ºC to +65ºC |
Life Expectancy | 200,000 Random Operations |
Handle Height | 51 mm |
Mounting | Below Panel |
IP Rating | IP40 |
