JL30H-XI-10R1GH

Compact single axis industrial joystick. Spring return to center. Hall effect potentiometer; 0.5V to 4.5V output. ±20º lever deflection. IP65. 2,000,000+ operations.
SKU:
712112
Condition:
New

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

Buy 5 - 9 and pay only $178.00 each
$187.00

Specifications

Attribute Value
Series / Type JL30H- Hall Effect Joystick
Number of Axis Single
Handle Deflection ±20º (40º overall)
Handle Operating Pattern Single axis
Handle Shape Flat shape (type 'H', see pdf)
Spring Return to Center Yes
Spring Return to Center Accuracy 50% 5%
Supply Voltage 5VDC ±10%
Output Voltage 0.5 - 4.5V (2.5V center)
Pushbutton on Handle No
Pushbutton Rating n/a
Center Detect Micro-Switch No
Directional Micro-Switches No
Micro-Switch Rating n/a
Operating Temperature -20ºC to +60ºC
Rubber Boot Yes
Mounting Plate No
Life Expectancy  >2,000,000 Random Operations
Mounting Below panel
IP Rating IP65
Output Cable 300mm length (AWG20)



Main Features

* Compact single axis joystick

* Hall effect potentiometer

* 0.5V to 4.5V output

* Spring return to center

* Paddle shaped handle

* IP65

* 2,000,000+ operations life

Customization

* Handle shapes

* Without rubber boot

* Dual output

Applications

* Material handling equipment

* Robotics

* Hand held control devices

* Electric lift trucks

* Construction equipment

* Marine controls

* Input device for automation purposes
