Specifications
| Attribute | Value |
| Type | Open frame. Precision. Long life. |
| Measuring Distance (Stroke Length) | 100, 150 and 200 mm |
| Mechanical End Stops | No |
| Element | Conductive Plastic |
| Resistance Value | 100mm (5k ohm), 150mm (7.5k ohm), 200mm (10k ohm) / ±30% |
| Linearity | ±1% |
| Resolution | Infinite |
| Power | 50 mW (100mm), 75mW (150mm), 100mW (200mm) |
| Operating Temperature | -3ºC to +85ºC |
| Life Expectancy | >5,000,000 Reciprocating Motions |
| Dimensions | 17 W x 6 H mm (length varies with stroke length, see pdf datasheet) |
| Mounting | Screw Hole |
| IP Rating | IP40 |
Main Features
The MBX series is a precision linear motion conductive plastic potentiometer in an open frame housing. It is a shaftless design featuring a sliding cursor (wiper).
Main Features:
* Low profile
* 100mm up to 200mm stroke lengths
* Aluminum housing
* Precision
* Long life
Customization
Customization:
* Non standard (fractional) measuring stroke lengths
* Improved linearity and/or resistance tolerances
* Customer specified pre-wiring / connectorization
Applications
Applications:
Optimized to be used as a feedback sensor (closed loop) in industrial applications.
* Medical devices
* Robotics
* Test Stands
* Aerospace
