MT12C Series

12mm diameter precision wire-wound potentiometer. Available in 3 turns (1080º), 5 turns (1800º) and 10 turns (3600º). 3.17mm (1/8") shaft diameter. High resolution. Suitable as panel controller or feedback sensor in industrial control applications. Customs welcome, please provide details.
SKU:
MT12C-5 R5K ±3% L0.35% (211221)
$46.00

Pdf Download PDF Ask A Question

Specifications

Attribute Value
Series / Type MT12C / Wire-Wound Multi-Turn Potentiometer
Mounting / Bearing Bushing Mount / Sleeve Bearing
Number of Turns 1800º (5 Turns) / 3600º (10 Turns)
Resistance Value 100, 200, 500, 1k, 2k, 5k, 10k, 20k ohms ±3%
Linearity 0.35% (5 turns) / 0.25% (10 turns)
Resolution Varies with resistance value (see pdf datasheet)
Operating Temperature -55ºC to +105ºC
Power 0.5W (5 Turns) / 1.0W (10 Turns)
Life Expectancy 500,000 Turns Life (5 Turn Models) / 1,000,000 Turns Life  (10 Turn Models)
Body Diameter 12 mm
Shaft Diameter 3.17 mm (1/8")
Shaft Length 20.6 mm
IP Rating IP40
